ADC Spectrum for APD [20°C]

Pulse Driver configuration: Delay: 65ns Width: 20ns Vpeak: 1.7 V (HIL: 1.7V - LOL: 0.0V) Rate: 308 Evts/s

Gate Width: 205ns

Temp Setup: 20°C Temp Cooling Bath: 20°C

Lapse between measurements: 20mins
