File:26.00Histo MinRNS.gif

Size of this preview: 800 × 475 pixels. Other resolution: 966 × 574 pixels.

Original file ‎(966 × 574 pixels, file size: 13 KB, MIME type: image/gif)

ADC Spectrum for APD [26°C]

Pulse Driver configuration: Delay: 65ns Width: 20ns Vpeak: 1.5 V (HIL: 1.5V - LOL: 0.0V) Rate: 307 Evts/s. LEE/TRE: 4.5ns

Gate Width: 205ns

Temp Setup: 26°C Temp Cooling Bath: 26°C

Lapse between measurements: 30mins
