Pulse Driver stability test (HP8112A):
Pulse Width: 20ns Delay: 150ns Amplitude: -0.5V Rate: 201
The pulse driver has NOT been rebooted between measurements of ~10k events (the voltage has been dropped to zero after the first 10k events and keep it to zero voltage for the next 5k events) the intervals between measurements is ~1h.
