Pulse Driver HP 8112A Stability - Time Series. The same measurement has been done three times (50k events each) and they are being presented in a single graph.
Pulse driver configuration: Width: 20ns Amp: -0.5V Delay: 150ns Rate: 483 Evts/s (Using external trigger)
File history
Click on a date/time to view the file as it appeared at that time.
| Date/Time | Thumbnail | Dimensions | User | Comment | |
|---|---|---|---|---|---|
| current | 14:21, 19 May 2017 | | 696 × 474 (18 KB) | Andres (talk | contribs) | Pulse driver stability test (Time Series): Pulse Width: 20ns Delay: 150ns Amplitude: -1.0V Rate: 483 Every measurement (~10k events) has been done after rebooting the pulse driver. |
| 16:45, 16 May 2017 |  | 696 × 474 (12 KB) | Andres (talk | contribs) | Pulse Driver HP 8112A Stability - Time Series. The same measurement has been done three times (50k events each) and they are being presented in a single graph. Pulse driver configuration: Width: 20ns Amp: -0.5V Delay: 150ns Rate: 483 Evts/s (Using exter |
